Devi Valves & Cocks · Brass Valves & Cocks
Devi Brass Regulating Tee
ISI Marked · Class 1Brass regulating tee with screwed-in bonnet and integral seat rising stem, to IS 778-1964 Class-1.
- Pressure rating
- Body 1.5 MPa / Seat 1.0 MPa (Hyd.)
- Size range
- 15mm
- Product standard
- IS 778
- Body material
- Forged Brass
Specifications
| Pressure Rating | Body 1.5 MPa / Seat 1.0 MPa (Hyd.) |
|---|---|
| Testing Standard | IS 778-1964 Class-1 |
| Product Standard | IS 778 |
| Size Range | 15mm |
| End Connection | Screwed BSP (IS 554) |
Key Features
- Screwed-in bonnet, inside screw
- Integral seat rising stem with back seat arrangement
- Sturdy tee handle
- Body test pressure 1.5 MPa, seat test 1.0 MPa
- Screwed female ends (BSP)
Applications
- Throttling and flow regulation duty
- Boiler feed and process water lines
- Municipal water supply networks
Available Sizes
Swipe the table sideways →
| Nominal Size (inch) | Nominal Size (mm) | Standard |
|---|---|---|
| 1/2" | 15 mm | IS 778 |
Full face-to-face and end-to-end dimension tables are printed on the downloadable tech sheet for this product.
Material Specification
Swipe the table sideways →
| Part | Material | Specification |
|---|---|---|
| Body | Forged Brass | IS 6912 |
| Stem | High Tensile Brass | IS 320 |
| Handle | Brass | — |
